| Features: | |
Simple Design + Simple Operation The design was inspired from the shape of firefly. The smart design largely saves space for doctors compared with built-out camera. We have preset many camera setups so the user does not need to set many parameters before using the device. The user can operate the machine directly once the installation has been finished. The device carries following automatic functions for photo shooting and processing when equipped with our MediView software: Auto Focus/ISO Auto Exposure Auto White Balance Right/Left Eye indicator Auto Focusing Calibration Adjustable Aperture The aperture can be adjusted at 7 different levels to meet different view of depth and brightness demands. HDMI output The HDMI output can be used to connect the S390H/S390L slit lamp with monitor. The doctors can share the live eye examination status simultaneously with patient’s family members or students for teaching purpose. | |
| Specifications: | |
| Microscope | |
| Microscope | Galilean Type |
| Magnification Change | Revolving Drum |
| Total Magnification | 6X, 10X, 16X, 25X, 40X |
| Eyepieces | 12.5X |
| Angle between Eyepieces | 13° |
| Pupillary Adjustment | 52 mm-78 mm |
| Diopter Adjustment | ±6.0 D |
| Field of View | Φ34.7 mm(6X), Φ22 mm（10X）, Φ13.5 mm(16X), Φ8.5 mm（25X）, Φ5.5mm(40X) |
| Instrument Base | |
| Longitudinal Movement | 110 mm |
| Lateral Movement | 110 mm |
| Vertical Movement | 30 mm |
| Fine Base Movement | 15 mm |
| Chin-rest | |
| Vertical Movement | 80 mm |
| Fixation | LED |
| Slit Illumination | |
| Slit Width | 0~14 mm continuous (slit becomes a circle at 14 mm) |
| Slit Length | 0~14 mm continuous |
| Aperture Diameter | Φ14 mm, Φ10 mm, Φ5 mm, Φ3 mm, Φ2 mm, Φ1 mm, Φ0.2 mm |
| Slit Angle | 0°~180° |
| Slit Inclination | 5°, 10°, 15°, 20° |
| Filters | Heat-absorbing filter, ND filter, Red-free filter, Cobalt Blue filter |
| Lamp | 6V/20W Halogen Lamp |
| Luminance | ≥50 KLX |
| Power Supply | |
| Input voltage | 220 V/110 V±10% |
| Input frequency | 50 Hz/60 Hz |
| Power Consumption | 30 VA (max) |
| Output voltage | Lamp 6V, Fixation 3V |
| Packaging | |
| Dimension | 770 mm x 470 mm x 570 mm(L/W/H) |
| Weight | Gross weight 26kg Net weight 18kg |
| Digital Module Specification | |
| Image Sensor | 500 Pixels |
| Photo Resolution | 2592 X 1944 |
| Format | JPEG |
| Video Resolution | 1280 X 960 |
| Frame of Video | 25 fps |
| Video Formats | MP4 |
| Focus Mode | Auto Focus |
| Exposure | Auto Exposure,Auto Gain |
| Transmission Interface | Standard USB Port |
